The outer ring or inner ring of two-row tapered roller bearing is a whole unit. ZWA’s two-row tapered roller bearings can be divided into metric and imperial ones. For metric tapered roller bearings, ZWA, as a leading China tapered roller bearing factory, will match the tolerance and dimension of spacers for the two single-row tapered roller bearings before delivery. For the imperial tapered roller bearings, it mainly contains TDI (one complete inner ring and two single outer rings, it’s usually supplied together with outer spacer)and TDO(one complete outer ring and two single inner rings) structure. The rotating precision of metric and imperial tapered roller bearings is different.
Features of Double Row Tapered Roller Bearing
1. High load capacity
2. Continuous rotating
3. Bearing radial and Bi-direction axial load.
4. High stiffness
5. Lower friction
6. Longer service life
7. Widely application
Specification of Double Row Tapered Roller Bearing
Standard bearings are provided as open. Sealed spherical can be made available upon request.
Many clearance options to choose from. (C0-C5)
Bearings can be offered in different heat treatments. (S0-S4)
Standard bearings are rated up to 302o F.
Primarily supplied with either a steel cage or a machined brass cage.
Tapered bore is available. (K)
The lubrication grooves area is available on either the outside diameter (W33) or the inner ring & outer ring. (W513)
Bearings are manufactured in normal tolerance classes.
Dimension and Parameters of Double Row Tapered Roller Bearing
