The Differences Between Sealed and Open Spherical Roller Bearings

The Differences Between Sealed and Open Spherical Roller Bearings

Sealed and open spherical roller bearings differ in their sealing arrangements. And their suitability for mining equipment depends on specific application requirements. Here are the key differences and considerations:


1. Sealed Spherical Roller Bearings:

Integrated seals designed to prevent the ingress of contaminants equip sealed spherical roller bearings.

Such as dust, dirt, and moisture into the bearing. These seals provide a barrier that helps retain lubrication.



Enhanced Protection:

Sealed bearings offer improved protection against contamination. This making them suitable for applications where dust, dirt, and moisture are prevalent. Such as in mining environments.

Reduced Maintenance:

Sealed bearings require less frequent maintenance and lubrication. Reducing downtime and maintenance costs.



Limited Operating Speed:

Sealed bearings may have lower operating speeds compared to open bearings due to the additional friction.

Temperature Limitations:

Sealed bearings may have temperature limitations due to the sealing material's capabilities. High-temperature environments may require alternative sealing arrangements or open bearings.


2. Open Spherical Roller Bearings:

Open spherical roller bearings do not have integrated seals and are exposed to the external environment. ZWA design these bearings without any suffixes indicating sealing arrangements.



Higher Operating Speeds:

Open bearings generally have higher operating speeds due to the absence of seals, resulting in lower friction.

Higher Temperature Capability:

Open bearings may have higher temperature capabilities. As they lack seals that can be susceptible to temperature limitations.



Increased Contamination Risk:

Open bearings are more susceptible to contamination from dust, dirt, and moisture. These factors can impact their performance and service life.

Regular Maintenance:

Open bearings require regular maintenance. Including appropriate lubrication and protection from contaminants, to ensure optimal performance and longevity.


Selection for Mining Equipment:


The choice between sealed and open spherical roller bearings depends on the specific conditions and requirements of the application. In mining environments where there is a high presence of dust, dirt, and moisture. Sealed bearings are often preferred due to their enhanced protection against contaminants.

Sealed spherical roller bearings can help extend the bearing's service life, reduce maintenance needs. And improve equipment reliability. However, in applications with higher operating speeds or elevated temperatures. Open bearings may be more suitable. It is essential to consider factors. Such as environmental conditions, operating speeds, temperature range, maintenance capabilities. And equipment specifications when selecting the appropriate bearing type for mining equipment.

ZWA Mine Bearings deliver exceptional performance, extended service life, and minimal maintenance. With superior durability and load-carrying capacity. Trust ZWA for optimal productivity and efficiency in your mining operations. Experience the difference today!
